Acoustic wall ties for supporting concrete, timber or metal studwork to provide stability along with acoustic isolation.
Acoustic wall ties provide an anti-vibration break between wall leafs. Manufactured in multiple formats to suit different applications and installation techniques.
They are ideally suited for stabilising walls exceeding 3.5m height. Acoustic wall ties should be installed at 1.5m height intervals.
Generally, for a wall of 4.5 meters, the EP mounts should be installed at 1.5m and 3m.
An Acoustic wall tie range designed for the floating suspension of soundproofed timber or metal stud walls and ceilings. Sylomer® avoids the transmission of vibrations while providing optimal acoustic results. They have a “FAIL SAFE” rugged metal structure, which is overload-proof.
Recommended for applications where fire or impact resistance is necessary. These mounts are also suitable for the isolation of vertical pipes, or any type of lightweight ducts that need to be isolated.
The tongues can be bent away or cut so as to accommodate a variety of depths with a maximum of around 150mm.
Four variants are available with loadings of 15kg, 30kg, 50kg and 75kg. Far superior to the standard BG type GL brackets.
Particularly suited for timber or metal frame supports.
mount designed for vibration damping of walls, equipped with long ring-attached screws for threading onto wooden or plastered walls. Maximum load per damper 10kgs.
Acoustic Wall Tie designed for vibration damping of walls, equipped with flanges for securing into concrete. Maximum load per damper 10kgs.
Acoustic wall tie designed for vibration damping of walls, equipped with flange and angle for securing into concrete/timber. Maximum load per damper 10kgs.
Acoustic wall tie designed to be screwed into the support profile, with the option of choosing different distances thanks to its 3 holes. The anchoring in to the wall is made by 2 fixing flanges.
Acoustic wall tie designed to be fixed between two elements through two metal parts with ‘pre-drilled holes’. The metal parts are easy to cut in order to adapt better to each project.
Acoustic wall tie designed to be fixed between two elements through two metal parts with ‘pre-drilled holes’. The metal parts are easy to cut in order to adapt better to each work. Can be used for a variety of applications. Please contact us if you need a more adaptive system for your project.
